M6 x 15.5mm Aluminium Grooved Countersunk Head, Open End Rivet Nut, Grip range 1.50 – 4.0mm, Hole Size 9.0mm
£0.05 - £0.08
Excluding VAT
SKU: 54035.600.001
Grip Range: 1.50 – 4.0mm
Internal thread size: M6 x 1.0mm pitch
Drill/hole diameter: 9.0mm
Body Diameter: .8.9mm
Head Diameter: 11.5mm
Head Height: 1.5mm
Available
Manufactured from aluminium for light weight, easy setting and resistance to corrosion
Sizes shown are thread size x original length
For best results, hole diameter should be 0.1mm larger than rivet nut body
Grip range: Minimum and maximum material thickness into which the nut can be set
